RCL SERIES COLUMN LOAD CELLS RCL SERIES COLUMN LOAD CELLS Applications
Compression load cells for CE-M approved weighbridges, tanks, silos, etc. Made in stainless steel. C3 AND C4 PRECISION CLASSES;STAINLESS STEEL CONSTRUCTION;IP68 PROTECTION LEVEL; MAX. CAPACITIES FROM 7500 TO 40000 kg SHIELDED CONNECTION CABLE
 | Standard Features - Minimum load cell verification interval: Vmin=EMax/15000
- Maximum number of verification intervals: nLC=3000 (C3) and 4000 (C4)
- Combined error: 0,0020% (C3) and 0,0018% (C4) of Full Scale Output (F.S.)
- Full Scale Output: 2mV/V +/- 0,1%
- Temperature effect on zero: +/- 0,0009% /XC
- Temperature effect on full scale output: 0,001%/XC (C3) and 0,0008%/XC (C4)
- Compensated Temperature Range: V10XC/+40XC
- Operating Temperature Range: V40XC/+80XC
- Creep error after 30 minutes: 0,025% F.S. (C3) and 0,018% F.S. (C4)
- Excitation voltage from 5 to 15 VDC
- Input Resistance: 1106 5 Ohm
- Output Resistance: 1000 1 Ohm
- Zero Balance: +/-1% F.S.
- Insulation Resistance: > 5000 MOhm
- Safe Overload: 200% F.S.
- Ultimate Overload: >300% F.S.
- 7.5, 15, 22.5t capacities: 4-wire shielded cable, 12m long, 5 mm diameter
- 30, 40, 50t capacities: 4-wire shielded cable, 18m long, 7,8 mm diameter
|  | Models - RCL7C3:7500 kg
- RCL15C3:15000 kg
- RCL22C3:22.500 kg
- RCL30C3:30000 kg
- RCL40C3:40000 kg
- RCL30C4:30000 kg
- RCL40C4:40000 kg
Options/Accessories - ATEX Certification (with surcharge)
- Assembly kit
- KRCL:Kit of jointed plates for selfalignment |
|
