| Standard Features - Large .8' (20.3 mm) Light Emitting Doide (LED) Display
- Full numeric keypad
- Nema 4X/IP66 stainless steel washdown enclosure
- Power for eight 350-ohm load cells or sixteen 700-ohm load cells
- Configurable analog to digital measurement rate
- Primary/secondary units configuration: lb, kg, ounces, short tons, metric tons, grams, or none
- Two independent communication ports: (2) full duplex, (1) unidirectional active 20 mA current loop
- Standardized EDP command sets
- Programmable ticket formats up to two 300-character printouts
- Full front-panel digital calibration and configuration
- Universal mounting stand
- Three-stage digital filtering
- Consecutive transaction numbering
- Two digital inputs, two digital outputs
- Time & date
- Count mode
Options/Accessories
- Analog output: selectable 0-10V, 4-20mA
- Revolution™ lll software
- Additional operating manual
Models
- 420, 115 VAC
- 420, 230 VAC, NEMA 5-15 plug
- 420, 230 VAC, CEE 7/7 plug
- 420, 9-36 VDC
|
