| Applications - Truck scales
- Industrial weighing
- Filling and checkweighing
Standard Features
- Bright Light Emitting Diode (LED) display
- AC power
- Stainless steel NEMA 4X enclosure
- Front-panel digital calibration
- Automatic zero and span temperature compensation
- Excitation for eight 350W load cells at 10 VDC
- Two fully programmable setpoints with Zero Band
- Two serial ports offering bidirectional RS-232 and simplex
- RS-232 or 20 mA current loop
- Gross/Tare/Net computation
- Time and date
- Accumulator
- 300-truck ID memory
- Versatile tilt stand
- Set-up parameters printout
Options/Accessories
- KBT7116-5 Panel mount kit*
- 2 Unlatched solid state output relays
- Unlatched dry contact 4-relay board
- BCD output (external)
- Analog output 0-10 VDC or 4-20 mA
- Analog output 0-10 VDC or 4-20 mA (internal mount)
- Analog output 0-10 VDC or 4-20 mA (internal mount, 16-bit new version)
- Combination relay and analog board
- Technical manual
- Additional operating manual
* Panel mount kit is not NEMA rated |
